Precision Sensing. Safer World
Featuring the innovative UAR technology (enables adaptive waveform dynamic adjustment), advanced ultra-high-definition 4D/UHD imaging, and AI-powered algorithms, ARCOS millimeter wave radar enables precise range, speed, and azimuth measurement, along with accurate target recognition, classification, and posture analysis.
With a flexible, configurable software platform, the radar maintains stable and reliable performance even in challenging environments such as rain, snow, or fog—delivering robust sensing capabilities for a wide range of intelligent applications.
√ All-weather reliability, unaffected by rain, snow, fog, dust or dirt
√ Multiple Interfaces supports, including UART, RS485, CAN, as well as level-triggered outputs
√ Compatible with various mounting brackets to simplify installation
√ IP67-rated for excellent water and dust resistance
√ Modular & customizable motherboards
Available products in this category
Key Perception Feature Highlights
Powerful detection capabilities
Ultra long range
Up to 500m
Perception Target Classification
Distinguish between large, medium, and small vehicles
Precise Multi-Target Detection
Distance resolution of 0.6 m, up to 512 targets
Ultra-wide field of view
FoV with a 120° broad beam, capable of covering up to 10 lanes.
Wide speed range
Detects vehicles from -300 to 300 km/h, ideal for highways and urban expressways.
Support Radar-Vision fusion optional
PTP time synchronization
Ensures accurate time alignment between the radar and camera
Support GPS
One-click radar coordinate mapping for visualized device management.
Gyroscope-assisted
Calculates precise horizontal distance between radar and targets for improved radar–vision fusion.
2-levle data fitting
Clustered target data and raw point-target data
Flexible configuration for seamless adaptation to various scenarios
Intersection Mode
Short range, enhanced static object detection, supports stop-and-reside.
Roadway Mode
Balanced static and dynamic detection, supports speed and wrong-way detection。
Highway Mode
Enhanced dynamic detection, long range, wide speed coverage.
Forward Installation
Adaptable for gantry mounting
Side Installation
Suitable for pole mounting
Typical Applications Architecture
Applications
Traffic Signal Optimization
Holographic Intersections
Oncoming Vehicle Warnings
Road Safety Alerts
Road Traffic Statistics
MR-VA704S
77GHz 4D High-Resolution Imaging Radar Detection 40m cover 150°
MR-VA702M
77GHz Mini Dual Wide-Angle Obstacle Avoidance Radar Detection 20m cover 120°
MR-VA717
77GHz Vehicle Front Obstacle Avoidance Radar Detection 170m cover 90°
MR-UA808
80GHz UAV Obstacle Avoidance Radar Detection 80m accuracy 0.18m
Key Perception Feature Highlights
Powerful detection capabilities
4D detection enables height sensing and supports filtering out lamp posts.
Dual wide-angle detection for a broader, more three-dimensional field of view.
Small blind zone detection — based on angular calculation, it is only one-quarter of that of mainstream radars in the industry.
Compact design, easy installation
Rich interface design
Supports UART, CAN, and RS485, plus level-output interfaces. The radar can directly drive two alarm outputs, eliminating the need for additional processing devices and reducing costs.
Ultra-compact size
Saves space and offers a clean, attractive installation.
Multiple mounting brackets
Supports various adjustable-angle brackets to simplify installation and save time.
Flexible configuration and easy to use
Customizable alarm zones
Support filtered by speed, area, and angle.
Multi-scenario adaptation
Support 3 modes: standard obstacle avoidance, lift platform, and anti-contact line
Multiple defense zones
Supports 3 zones with customizable alarms.
Ten-level sensitivity settings
Adjustable levels 1–10, lower increases sensitivity, higher reduces false alarms.
Typical Application
Execution Layer
Responsible for vehicle actuation and real-time control. It executes control commands and provides feedback to lower-level modules to accomplish driving tasks such as braking, steering, and speed control.
· Braking Control
· Steering Control
· Deceleration / Speed Control
Decision-Making Layer
Processes perception data to make driving decisions and judgments, generates appropriate control strategies, and replaces human decision-making in driving scenarios.
· Onboard Computing & Control Algorithms
(Receives data from the perception layer and outputs vehicle control commands)
Perception Layer
Acquires environmental and vehicle-state information to support decision-making and control.
· Millimeter-Wave Radar
· LiDAR
· Ultrasonic Sensors
· Cameras
· Other Perception Sensors
Application
Forklift Collision Prevention
Pipe Laying Collision Prevention
Construction Vehicles Collision Avoidance
Unmanned Sweeper Surround Obstacle Avoidance
Engineering Vehicles Collision Prevention
Robots Surround Obstacle Avoidance
Autonomous Shuttle Obstacle Avoidance
Key Perception Feature Highlights
Powerful detection capabilities
Support target tracking and trajectory recording
When a target enters the protection zone, radar tracks targets’ direction and distance in real time, triggering active alarms.
Intelligent Zone Monitoring, Focused on What Matters
Define filtering, warning, and alarm zones for precise, layered detection.
Supports target recognition and classification
Intelligently classifies targets—people, vehicles, or trees—using machine learning.
Feature-rich and highly flexible, meeting a wide range of application needs
PoE power supply
Supported on selected models
Local alarm output
Multiple interface outputs with built-in 4ch audio-visual alarm output
Flexible installation options
Support clamp or bracket installation
One-click scene selection
Software-supported
One-click radar-camera alignment
Software-supported
Visualized interface
Software-supported
Radar-vision fusion with multi-radar and multi-camera configuration, delivering full 360° coverage with no blind spots
Multi-Sensor Radar
Single radar with multiple sensors, linked across different positions.
Target tracking
Support target tracking and trajectory recording.
Detection of multiple motion patterns
Crouching, crawling, walking slowly, running
Web-based all-in-one management, plug and play
Web Access
No software download required; accessible anytime, anywhere.
One-Stop Management
Plug in and use immediately, no configuration required.
Full-Featured
Web interface supports preview, grid, alarms, computation, and management functions.
Typical Applications Architecture
Benefits at a glance
Multi-Angle Full-Coverage Video Viewing
Eliminates visual blind spots, provides comprehensive awareness of the surrounding environment, and enables timely detection of suspicious targets.
Proactive Early Warning
Multi-technology integration creates a comprehensive defense system for active detection and
prevention.
Mid-Incident Warning
Centralized monitoring and dispatch across all sites enables timely alerts to border personnel upon
detecting intrusions, while simultaneously deterring intruders and prompting them to abandon their
attempt.
Post-Incident Verification
Collects evidence, reviews the entire event, and summarizes the intrusion incident.
Simple, Fast, and Efficient
The management system is easy to operate, devices are integrated for easy maintenance, and signal
acquisition and storage are quick and efficient.
Reduced False Alarms, Improved Accuracy
Multi-technology integration ensures high system reliability, enabling 24/7 unmanned operation.
Typical Applications Architecture
Border & Coastal Defense
Airports & Military Facility Protection
Energy Facility Protection
Key Perception Feature Highlights
Powerful detection capabilities
High Precision
Achieves centimeter-level ranging accuracy (±0.02 m), more than twice that of similar products.
Small Blind Zone
Blind zone of only 0.2 m, more than twice as good as similar products.
Long Range
Supports a maximum height-measurement distance of 1000 m, stable at 800 m
Compact design, easy integration
More interfaces, greater flexibility
Supports UART/CAN/RS232/RS422/RS485 to meet diverse integration needs and enable efficient system connectivity.
Lightweight & Low Power
Weighs little and consumes as low as 1.8W, reducing UAV load and maintaining strong flight endurance.
Compact Size, Broad Compatibility
Single-chip integration greatly reduces size, making it compatible with various UAV types and specifications.
Seamless Integration with Open-Source Flight Controllers
Officially compatible with APM & PX4, enabling plug-and-play use and offering a streamlined sensing-to-control solution.
Stable and reliable data performance
Data no sudden jump
Uses static clutter suppression algorithms, ensuring consistent radar output.
Self-Check of Hardware and Software
Integrated hardware and software self-check functions help verify data accuracy, enhancing safety and ensuring reliable output.
Multi-Sensor Fusion
Integrates a six-axis gyroscope, accelerometer, and magnetometer to monitor UAV status, issuing tilt warnings to keep the radar level for optimal performance.
Applications
